KEXINT GJFJBH Indoor Flat Fiber Cable Duplex Aramid Yarn Strengthened Interconnect

Name: KEXINT GJFJBH Indoor Flat Fiber Cable Duplex Aramid Yarn Strengthened Interconnect
Brand: KEXINT
Price: 0.04 USD

Wholesale KEXINT GJFJBH Indoor Flat Fiber Cable Duplex Aramid Yarn Strengthened Interconnect from china suppliers

Brand Name : KEXINT

Model Number : GJFJBH

Certification : CE/ROHS/ISO9001

Place of Origin : CHINA

MOQ : 1+KM

Price : 0.04+$+m

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Supply Ability : 1000+km+Day

Delivery Time : 10

Packaging Details : roll

Color : Yellow or customized

Jacket Material : LZSH or customized

Length : Customized

Application : Indoor

Fiber Type : G657A1 or customized

Strength Member Material : Aramid Yarn

Fiber Core : 2 cores

Storage temperature : -60~+80℃

Contact Now

KEXINT Duplex Aramid Yarn Strengthened Interconnect Flat Indoor Fiber Cable GJFJBH

The structure of GJFJBV/H double-core optical cable is based on ф900μm or ф600μm tight-buffered optical fiber as the basic unit. Outside the tight-buffered optical fiber unit, multi-strand aramid yarn or high-strength glass yarn is evenly spread to strengthen, and then extruded polyvinyl chloride (PVC) Or low-smoke halogen-free flame-retardant polyolefin (LSZH) outer sheath. GJFJBV/H is used for the connection of communication equipment, 0.9 tight package and easy to peel, aramid yarn as a reinforcing element, which makes the optical cable have excellent tensile strength, and the non-metallic all-dielectric structure protects it from electromagnetic influence.


Features:
· High-strength aramid yarn enhances the tensile strength of optical cables
·The outer diameter of the tight-buffered fiber is uniform and the stripping property is good Stable performance at high and low temperatures
·The outer protection material has the advantages of corrosion resistance, waterproof, UV protection, flame retardant, environmental protection, etc
. 8-shaped structure sheath is easy to peel off the branch for use


Application:

·data communication
·Optical linker production
·Laying method: indoor shaft, horizontal wiring
· Duplex fiber optic active connection patch cord or pigtail



Technical Parameters:

Tensile Strength	Long term	120N	120N	80N	60N
Tensile Strength	Short term	250N	250N	150N	120N
Crush Resistance	Long term	100N/100mm	100N/100mm	100N/100mm	100N/100mm
Crush Resistance	Short term	500N/100mm	500N/100mm	500N/100mm	500N/100mm
Bending Radius	Dynamic	20XD	20XD	20XD	20XD
Bending Radius	Static	10XD	10XD	10XD	10XD


Optical Characteristics:

G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0dB/km	≤3.0dB/km
	@1300nm			≤1.0dB/km	≤1.0dB/km
	@1310nm	≤0.36dB/km	--
	@1550nm	≤0.22dB/km	≤0.23dB/km
Wavelength (Class A)	@850			≥500MHZ·km	≥500MHZ·km
Wavelength (Class A)	@1300			≥1000MHZ·km	≥600MHZ·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength		≤1260nm	≤1480nm


Product Standards:
GJFJBV/H optical cable complies with YD/T1258.2-2009, ICEA-596, GR-409, IEC794, etc.; and meets UL certification requirements for OFNR and OFNP.
