KEXINT GJFJHV Fiber Optic Cable FTTH Singlemode / Multimode Indoor Branch Cable

Brand Name : KEXINT

Model Number : GJFJHV

Certification : CE Iso-9001 Ross UL

Place of Origin : CHINA

MOQ : 10+KM

Price : 124.36+$+km

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Supply Ability : 1000+km+Day

Delivery Time : 10

Packaging Details : box

Color : Customized

Jacket Material : LZSH or customized

Length : Customized

Fiber Type : SM MM

Application : Indoor

Strength Member Material : Aramid Yarn and FRP

Fiber Core : 4-144 cores

Contact Now

KEXINT FTTH Single-mode Multi-mode Indoor Branch Cable GJFJHV Fiber Optic Cable

The structure of GJFJHV optical cable is to place aramid fiber strength element on the surface of the tight-buffered fiber and then extrude the sheath to make a subunit. A layer of dry water blocking tape is wrapped around the sheath, and finally extruded into a PVC (or LSZH) sheath to form a cable.
Feature:
1.Each sub-cable contains aramid reinforced fiber, which has good bendability, does not contain grease, is hygienic and clean, and is easy to construct and connect.
2.The optical fiber in the sub-cable adopts a tight sleeve design, and has an independent strengthening element and sheath, which can prevent damage caused by the environment and mechanical stress.
3.Low-smoke, low-halogen, flame-retardant sheath, anti-flammability and self-extinguishing, suitable for indoor environments such as computer rooms, cable shafts and wiring inside walls.
4.Low-smoke, halogen-free, flame-retardant polyolefin sheath, anti-ultraviolet, waterproof, mildew-proof, and environmental stress cracking resistance; and no acid gas release, no corrosion of equipment in the computer room, suitable for indoor and outdoor use or indoor environments that require high flame-retardant grades (such as In-ceiling wiring, open-wire wiring, etc.) use
Application:
a. Indoor horizontal wiring, vertical wiring in buildings, LAN network.
b. Standard core mountable connectors for interfacing with equipment.
c. Used as the tail cable of the backbone network, it can be directly connected to the room from the outside, eliminating the need for a junction box, isolating lightning, and improving system reliability.
d. Suitable for floor connection and easy maintenance
KEXINT GJFJHV Fiber Optic Cable FTTH Singlemode / Multimode Indoor Branch Cable
KEXINT GJFJHV Fiber Optic Cable FTTH Singlemode / Multimode Indoor Branch Cable
Specification
item
value
Model Number
GJFJHV
Type
Indoor Fiber Optic Cable
Place of Origin
China
Guangdong
Brand Name
KEXINT
Number of Conductors
≥ 10
Color
Customized
Jacket Material
LZSH or customized
Length
Customized
Application
Indoor
Fiber Type
SM MM
Strength Member Material
Aramid Yarn and FRP
Fiber Core
4-144 cores
Storage temperature
-60~+80℃
Certification
CE/ROHS/ISO9001
